## brcon2024 - 2024-08-08

   title: Deep C programming - UNIX philosophy in distributed offshore systems

  author: Anders Damsgaard (adc)

 contact: [email protected]
          gopher://adamsgaard.dk
          https://adamsgaard.dk

  slides: gopher://adamsgaard.dk/0/tmp/brcon2024_adc.md

## brcon2024 - 2024-08-08

   title: Deep C programming - UNIX philosophy in distributed offshore systems

  author: Anders Damsgaard (adc)

 contact: [email protected]
          gopher://adamsgaard.dk
          https://adamsgaard.dk
<marquee><blink>
  slides: gopher://adamsgaard.dk/tmp/brcon2024_adc.md
</blink></marquee>


## Previously..
* brcon2020: Energy efficient programming in science
* brcon2021: Unix principles for science simulations
* brcon2022: Est. Bitreich Arctic Vault
* brcon2023: Using Unix and Bitreich tools for preparing scientific papers
* Today: UNIX philosophy in distributed offshore systems
#pause
* Tomorrow: UNOX philosophy in Vitré

## Outline
* How we can benefit from hyped technology with true and tried principles
* Overview of the offshore system
* The talk transitions into hands-on exercises
* Ask questions along the way in #bitreich-con

## Danish Geotechnical Institute (geo.dk)
* ~250 employees in Lyngby and Aarhus, Denmark
* Geotechnical investigations (onshore/offshore)
* Environmental consultancy
* Laboratory tests
* Geodata analysis
* Geoscientific software development

#pause
-> New offshore rig built from the ground up

## Offshore geotechnical investigations
                       .*          +------------------+
                       \|\         |         ,_____.  |
                   _============.  |         |     |  |
                    \\# # # #/  |  | ._______|--|--|  |
                     |          +.,| |  Geo  .--|--|  |
             _---------------------|-+-------|--|--|--|\
               \  MS/Bitreich      |         +--|--+  | |
~~~~~~~~~~~~~~~~~\~~~~~~~~~~~~~~~~~~|~~~~~~~~~~~~~~~~~~|~|~~~~~~~~~~~~
                 \                 +------------------+''  ~
                  \_________________________________/--+ ~ . ~~
                                                           ~


    ><>

                         <><



----------------------------------------------------------------------


## Offshore geotechnical investigations
                       .*
                       \|\                   ,_____.
                   _============.            |     |
                    \\# # # #/  |    ._______|--|--|
                     |          +.,  |  Geo  .--|--|
             _---------------------+-+-------|--|--|---\
               \  MS/Bitreich                +--|--+    |
~~~~~~~~~~~~~~~~~\~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~|~~~~~~~~~~~~
                 \                                   .-''  ~
                  \_________________________________/--+ ~ . ~~
                                                           ~


    ><>

                         <><



----------------------------------------------------------------------



## Offshore geotechnical investigations
                       .*
                       \|\                   ,_____.
                   _============.            |     |
                    \\# # # #/  |    ._______|--|--|
                     |          +.,  |  Geo  |  |  |
             _---------------------+-+-------|--|--|---\
               \  MS/Bitreich                   |       |
~~~~~~~~~~~~~~~~~\~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~|~~~~~~~|~~~~~~~~~~~~
                 \                              |    .-''   ~
                  \_____________________________|___/--x~ ~ . ~~
                                             .--|--.        ~
                                             |  v  |
                                             +-----+
     ><>

                        <><



----------------------------------------------------------------------




## Offshore geotechnical investigations
                       .*
                       \|\                   ,_____.
                   _============.            |     |
                    \\# # # #/  |    ._______|--|--|
                     |          +.,  |  Geo  |  |  |
             _---------------------+-+-------|--|--|---\
               \  MS/Bitreich                   |       |
~~~~~~~~~~~~~~~~~\~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~|~~~~~~~|~~~~~~~~~~~~
                 \                              |    .-'~ ~ . ~~
                  \_____________________________|___/--x    ~
                                                |
                                                |
                                                |
      ><>                                       |
                                                |
                       <><                      |
                                                |
                                             .--|--.
                                             |  v  |
----------------------------------------------+-----+-----------------




## Offshore geotechnical investigations
                       .*
                       \|\                   ,_____.
                   _============.            |     |
                    \\# # # #/  |    ._______|--|--|
                     |          +.,  |  Geo  |  |  |
             _---------------------+-+-------|--|--|---\
               \  MS/Bitreich                   |       |
~~~~~~~~~~~~~~~~~\~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~|~~~~~~~|~~~~~~~~~~~~
                 \                              |    .-''   ~
                  \_____________________________|___/--x
                                                |
                                                |
                                                |
       ><>                                      |
                                                |
                      <><                       |
                                                |
                                             .--|--.
                                             |  |  |
----------------------------------------------+--|--+-----------------
                                                |
                                                |
                                                |
                                                v

## Offshore geotechnical investigations
                                        |               |
                                        |               |
                                        |               |
                                        |               |
                                        |               |
                                        |               |
                                        |               |
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~|~~~~~~~~~~~~~~~|~~~~~~~~~~~~
                                        |               |
                                        |               |
                                        |               |
                                        |               |
                                 ?      |               |
                               ><>      |               |
                                        |               |
                                        |               |  !
                                        |               |  <><
                                        |               |
                                        |               |
-----------------------------------------|---------------|------------
                                        |               |
                                        |               |
                                        |               |
                                        |               |
                                        |_______________|

https://www.mdpi.com/energies/energies-17-01964/article_deploy/html/images/energies-17-01964-g001.png

## Offshore systems overview
* Up to 800 sensors, usually 1-10 Hz
* SCADA, PLCs, environmental sensors, navigation, scientific results,
 calibration data, ...
* Control messages
* Asynchronous data streams
* Event driven logic
* Raw sensor output into physical units
* Aggregation of time series and combination of sources
* Time series databases
* Development project with many involved partners

## Approaches: Unix philosophy vs. Microsoft mentality
* Does the client know what they want?
* Do we know everything about what we want to solve?
* Do we know if our assumptions are valid, in particular in complex systems?
* Do we have full specifications?
* Should we produce a big integrated C# monolith to handle computations,
 flow, storage, logic?

#pause
   > yes no | head -n 5


## Data routing system
* MQTT: Message Queuing Telemetry Transport
* Started as a proprietary protocol for SCADA systems in O&G
* Lightweight, publish-subscribe network protocol
* Constrained devices and low-bandwidth, high-latency networks
* Publish/Subscribe Model: Decouples message producers from consumers
* Data accessible via network, not living internally in an obscure program

Specifications:
- MQTT v5.0:    https://docs.oasis-open.org/mqtt/mqtt/v5.0/mqtt-v5.0.html
- MQTT v3.1.1:  http://docs.oasis-open.org/mqtt/mqtt/v3.1.1/os/mqtt-v3.1.1-os.html
- https://github.com/mqtt/mqtt.org/wiki/Differences-between-3.1.1-and-5.0
- MQTT and TLS: https://www.rfc-editor.org/rfc/rfc9431.txt

## Central concepts
* Broker: Central server that routes messages
* Clients: Devices that publish or subscribe to one or more topics
* Messages: Data packets sent between clients via the broker
* Topics: Hierarchical and dynamic name space for message

Libs for many languages, e.g.,
       - https://github.com/eclipse/paho.mqtt.c
       - https://github.com/eclipse/paho.mqtt.golang

## DISCLAIMER

The coming exercises mainly to demonstrate fundamentals and principles

Most are suboptimal or bad practice

But, let's have some #fun ...

## MQTT use cases
* Home thermometers and weather stations (if you ask the web)
* IoT Devices: Smart homes, wearables, and industrial automation
* Mobile Applications: Real-time messaging and notifications
* Remote Monitoring: Environmental sensors, health monitoring
* Connected Vehicles: Telematics and fleet management

## MQTT messages
* TCP/IP
* Limit to message size configurable

* New subscribers receive only new messages (no backlog)
* Retained Messages: Last known good value for new subscribers
* Last Will and Testament (LWT): Notifies other clients about an ungraceful disconnection

* Quality of Service (QoS): Three levels to ensure message delivery
* QoS 0: At most once delivery (fire and forget)
* QoS 1: At least once delivery (acknowledged delivery)
* QoS 2: Exactly once delivery (assured delivery)

## Why MQTT for the offshore project?
* Hierarchial data structure through topics
* A node in the topic tree exists as soon as someone publishes or
 subscribes to it
* Data accessible via network and all clients can read or publish
 (by default)

#pause
   rig/sensor1/raw
   rig/sensor1/phys
   rig/sensor2/raw
   rig/sensor2/phys
   ...
   ship/navigation/easting
   ship/navigation/northing
   ...

## Topic examples
Wildcards: #, +   (subscribe only)

Subscription examples:
   1) rig/sensor1/raw
   2) ship/#: Subscribe to everything from the ship
   3) rig/+/phys: Subscribe to all physical values

## Example: Subscribe and publish
$ cat bin/timestamp     # in case you don't have ts(1)
#!/bin/sh
while read -r REPLY
do
   printf '%s %s\n' "$(date '+%Y-%m-%d %Z %H:%M:%S')" "$REPLY"
done
#pause
$ export MQTTURI='mqtt://bitreich:[email protected]:65431/'
#pause
$ mosquitto_sub -L "${MQTTURI}#" -v -t '#' | timestamp | grep -v hatesensor
#pause

$ date | mosquitto_pub -L "${MQTTURI}$(hostname)/$(whoami)" -l

## Reporting online status via last will and retain, reporting some metrics

gophers://duckless.org/0/tmp/mqtt-online

#!/bin/sh
online_topic="${ONLINE_TOPIC:-$(hostname)/online}"
mqtt_broker="${MQTT_BROKER:-mx2.adamsgaard.dk}"
mqtt_port="${MQTT_PORT:-65431}"
mqtt_user="${MQTT_USER:-bitreich}"
mqtt_password="${MQTT_PASSWORD:-bitreich}"
args="-h ${mqtt_broker} -p ${mqtt_port} -u ${mqtt_user} -P ${mqtt_password}"
mosquitto_pub ${args} -t "${online_topic}" -r -m "1"
while :
do
   printf '%s\t%s\t%s\t%s\n' "$(date +%s)" "$(date)" "$(hostname)" "$(uptime)"
   sleep 360
done | mosquitto_pub ${args} --will-topic "${online_topic}" \
   --will-retain --will-payload "0" -t "${online_topic}" -r -l

## Data structure on the network
Interact with data hierarchy via small modular clients.
Brings all benefits of UNIX design into play.

The tenents of the UNIX philosophy:

   - Small is beautiful
   - Make each program do one thing well
   - Build a prototype as soon as possible
   - Choose portability over efficiency
   - Store numerical data in flat ASCII files
   - Use software leverage to your advantage
   - Use shell scripts to increase leverage and portability
   - Avoid captive user interfaces
   - Make every program a filter

src: Make Gancarz 1995 "The UNIX Philosophy", ISBN 1-55558-123-4

## Distributed computing
Assign small modular programs to read stdin from topics and post their
result to another topic

* Rudimentary distributed computing
* Each program acts as a text filter
* Each program can contribute local data

(disclaimer: for 1:1 connections, netcat or named pipes over SSH is simpler)

Broker statistics: $SYS/broker
       mosquitto_sub -L "${MQTTURI}\$SYS/broker/#" -v

## Connecting stdin, stdout, and stderr with MQTT topics
Full script: gophers://duckless.org/0/tmp/mqtt-wrapper

   fifodir="$(mktemp -d)" || die 'mktemp'
   fin="${fifodir}/in"
   fout="${fifodir}/out"
   ferr="${fifodir}/err"
   mkfifo "$fin" "$fout" "$ferr" || die 'mkfifo'

#pause
   mosquitto_sub ${mosquitto_args} -t $subscribe_args >"${fin}" &
   mosquitto_pub ${mosquitto_args} -t "${output_topic}" -l <"${fout}" &
   mosquitto_pub ${mosquitto_args} -t "${error_topic}" -l <"${ferr}" &
   trap -- 'cleanup' ERR INT HUP EXIT CHLD

#pause
   while :
   do
       $runtime $runtime_args <"${fin}" >"${fout}" 2>"${ferr}"
   done

## Connecting stdin, stdout, and stderr with MQTT topics (cont.)

Works if input is continuously evaluated (i.e., does not wait for EOF)

       RUNTIME=bc ARGS="-l" sh -x ./mqtt-wrapper
       RUNTIME=sh ARGS="your-favorite-cgi-script" sh -x ./mqtt-wrapper
       RUNTIME=sh ARGS="your-sd-program" sh -x ./mqtt-wrapper

## Outlook
* Lots of possibilities coupling pub/sub with text streams
* Use existing client/broker implementations and libraries
* Minimal C implementation would be nice, aiming at a subset of features
* Represent topic structure with virtual file system representation
 (i.e., plan9 or /proc in linux)

## Challenge 0: Installing a MQTT broker/client
Mosquitto (mostly C, BSD-like license).
Pretty bloated, a minimal alternative would be nice.
You just need the client for these exercises.

   https://github.com/eclipse/mosquitto

Package names in common OS:

   OpenBSD  mosquitto           broker+client
   Arch     mosquitto           broker+client
   Gentoo   app-misc/mosquitto  broker+client
   Debian   mosquitto-clients   client

## Challenge agenda
First one to post a working solution will get points towards a
price.

## Challenge 1: Let's write a chat
Hints:

   mosquitto_pub(1): Publish a message to a named topic
       Useful flags:
           -d: Show debug info
           -l: Read messages from stdin (each line 1 message)
   mosquitto_sub(1): Subscribe to a path in the topic hierarchy
           -d: Show debug info
           -v: Print topic for each received message as first field

   Connection URI:
       -L 'mqtt://bitreich:[email protected]:65431/testtopic'

Let's use the message format: "nick\tmessage"

## Challenge 2: Write a script that records the chat
Hint: The '#' wild card

What is the best choice for a time stamp?
* Time as the sender reports it?
* Time as the subscriber sees it?

## Challenge 3: Let the data flow
Anyone has a funky data source?

* USB body thermometer?
* spoon -t
* while :; do printf '%s\t%s' "$(hostname)" "$(uptime)"; sleep 10; done
* ii/annna?
* vmstat(8)

Task: Publish some data and let the others guess what it is.
The funkier, the better.

Message format ideas:
   TSV, JSON, XLSX? sfeed(5)?
   VT100 control codes??

## Challenge 4: Raise an alert!
Set up a script that monitors one of the data sources, and triggers
an alert upon a condition (email, xmessage, log line, ...).

## Challenge 5: Make some gnuplot
Monitor one of the sensors from the previous, and create a continuously
updating gnuplot (-t dumb) with a rolling window.

## Challenge 6: Health check reporting
Write a script that monitors some gopher and reports their status to

       gopherstatus/<uri>
               up|down

## Challenge 7: Tamagotchi
Make script that imitates a virtual pet, expecting to be feed
"cookies" as messages on stdin every 30 s.

It should die if it gets to much or too little food.

Report its happyness to a topic with ASCII smileys.

You are viewing proxied material from bitreich.org. The copyright of proxied material belongs to its original authors. Any comments or complaints in relation to proxied material should be directed to the original authors of the content concerned. Please see the disclaimer for more details.
